SOUNDIGITAL EVOX2 AMPLIFIERS

1200.2 EVOX2 – 2Ω

• Power @ 4Ω: 2 X 261 WRMS
• Power @ 2Ω: 2 X 396 WRMS
• Power @ 1Ω: 2 X 600 WRMS
• Bridge Power @ 4Ω: 1 X 792 WRMS
• Bridge Power @ 2Ω: 1 X 1200 WRMS
• Operating Voltage: 8V – 16V
• Current Draw (Music): 57 A
• Current Draw (Max): 115 A
• Recommended Fuse (Music): 60 A
• Total Efficiency: 83%
• Damping Factor: 200
• Frequency Response (-3dB): 5Hz – 22kHz
• SNR: 91dB
• Crossover HPF: 45Hz – 850Hz
• Crossover LPF: 45Hz – 850Hz
• THD + N (10% Rated Power): 0.1%
• Product Dimensions: 7.1 x 5.4 x 2.2 in
• Product Dimensions: 18.1 x 13.6 x 5.5 cm

1200.2 EVOX2 – 4Ω

• Power @ 4Ω: 2 X 396 WRMS
• Power @ 2Ω: 2 X 600 WRMS
• Power @ 1Ω: N/A
• Bridge Power @ 4Ω: 1 X 1200 WRMS
• Bridge Power @ 2Ω: N/A
• Operating Voltage: 8V – 16V
• Current Draw (Music): 57 A
• Current Draw (Max): 115 A
• Recommended Fuse (Music): 60 A
• Total Efficiency: 83%
• Damping Factor: 200
• Frequency Response (-3dB): 5Hz – 22kHz
• SNR: 91dB
• Crossover HPF: 45Hz – 850Hz
• Crossover LPF: 45Hz – 850Hz
• THD + N (10% Rated Power): 0.1%
• Product Dimensions: 7.1 x 5.4 x 2.2 in
• Product Dimensions: 18.1 x 13.6 x 5.5 cm

1200.4 EVOX2 – 2Ω

• Power @ 4Ω: 4 X 131 WRMS
• Power @ 2Ω: 4 X 198 WRMS
• Power @ 1Ω: 4 X 300 WRMS
• Bridge Power @ 4Ω: 2 X 396 WRMS
• Bridge Power @ 2Ω: 2 X 600 WRMS
• Operating Voltage: 8V – 16V
• Current Draw (Music): 49 A
• Current Draw (Max): 98 A
• Recommended Fuse (Music): 60 A
• Total Efficiency: 85%
• Damping Factor: 200
• Frequency Response (-3dB): 5Hz – 22kHz
• SNR: 91dB
• Crossover HPF: 45Hz – 850Hz
• Crossover LPF: 45Hz – 850Hz
• THD + N (10% Rated Power): 0.1%
• Product Dimensions: 7.1 x 5.4 x 2.2 in
• Product Dimensions: 18.1 x 13.6 x 5.5 cm

1200.4 EVOX2 – 4Ω

• Power @ 4Ω: 4 X 198 WRMS
• Power @ 2Ω: 4 X 300 WRMS
• Power @ 1Ω: N/A
• Bridge Power @ 4Ω: 2 X 600 WRMS
• Bridge Power @ 2Ω: N/A
• Operating Voltage: 8V – 16V
• Current Draw (Music): 49 A
• Current Draw (Max): 98 A
• Recommended Fuse (Music): 60 A
• Total Efficiency: 85%
• Damping Factor: 200
• Frequency Response (-3dB): 5Hz – 22kHz
• SNR: 88dB
• Crossover HPF: 45Hz – 850Hz
• Crossover LPF: 45Hz – 850Hz
• THD + N (10% Rated Power): 0.1%
• Product Dimensions: 7.1 x 5.4 x 2.2 in
• Product Dimensions: 18.1 x 13.6 x 5.5 cm

3000.1 EVOX2 – 1Ω

• Power @ 4Ω: 1 X 1307 WRMS
• Power @ 2Ω: 1 X 1980 WRMS
• Power @ 1Ω: 1 X 3000 WRMS
• Operating Voltage: 8V – 16V
• Current Draw (Music): 121 A
• Current Draw (Max): 242 A
• Recommended Fuse (Music): 140 A
• Total Efficiency: 86%
• Damping Factor: >2000
• Frequency Response (-3dB): 5Hz – 25kHz
• SNR: 90dB
• Crossover HPF: 5Hz – 30Hz
• Crossover LPF: 50Hz – 500Hz
• THD + N (10% Rated Power): 0.1%
• Product Dimensions: 8.9 x 5.4 x 2.2 in
• Product Dimensions: 22.7 x 13.6 x 5.5 cm

• 3000.1 EVOX2 – 2Ω
• Power @ 4Ω: 1 X 1980 WRMS
• Power @ 2Ω: 1 X 3000 WRMS
• Power @ 1Ω: N/A
• Operating Voltage: 8V – 16V
• Current Draw (Music): 121 A
• Current Draw (Max): 242 A
• Recommended Fuse (Music): 140 A
• Total Efficiency: 86%
• Damping Factor: >2000
• Frequency Response (-3dB): 5Hz – 25kHz
• SNR: 90dB
• Crossover HPF: 5Hz – 30Hz
• Crossover LPF: 50Hz – 500Hz
• THD + N (10% Rated Power): 0.1%
• Product Dimensions: 8.9 x 5.4 x 2.2 in
• Product Dimensions: 22.7 x 13.6 x 5.5 cm

5000.1 EVOX2 – 1Ω

• Power @ 4Ω: 1 X 2178 WRMS
• Power @ 2Ω: 1 X 3300 WRMS
• Power @ 1Ω: 1 X 5000 WRMS
• Operating Voltage: 8V – 16V
• Current Draw (Music): 202 A
• Current Draw (Max): 404 A
• Recommended Fuse (Music): 250 A
• Total Efficiency: 86%
• Damping Factor: >2000
• Frequency Response (-3dB): 5Hz – 6000Hz
• SNR: 90dB
• Crossover HPF/Subsonic: 5Hz – 40Hz
• Crossover LPF: 50Hz – 6000Hz
• THD + N (10% Rated Power): 0.08%
• Product Dimensions: 9.8 x 7 x 2.8 in
• Product Dimensions: 24.9 x 17.8 x 7.1 cm

5000.1 EVOX2 – 2Ω

• Power @ 4Ω: 1 X 3300 WRMS
• Power @ 2Ω: 1 X 5000 WRMS
• Power @ 1Ω: N/A
• Operating Voltage: 8V – 16V
• Current Draw (Music): 202 A
• Current Draw (Max): 404 A
• Recommended Fuse (Music): 250 A
• Total Efficiency: 86%
• Damping Factor: >2000
• Frequency Response (-3dB): 5Hz – 6000Hz
• SNR: 90dB
• Crossover HPF/Subsonic: 5Hz – 40Hz
• Crossover LPF: 50Hz – 6000Hz
• THD + N (10% Rated Power): 0.08%
• Product Dimensions: 9.8 x 7 x 2.8 in
• Product Dimensions: 24.9 x 17.8 x 7.1 cm
