ALPINE X-SERIES 4-CHANNEL AMPLIFIER/X-A70F

ALPINE X-A70F 4-CHANNEL AMPLIFIER

Good music needs big power

Alpine's X-Series X-A90F car amplifier will sharpen the focus of your music's stereo image, almost like the musicians are playing inside your car. This 4-channel amplifier puts out 120 watts RMS per channel, so you can be sure you'll get the big sound you want. You can also use this amp in 2-channel mode to power a couple subwoofers with 350 watts RMS each. Speaker-level inputs allow you to add this amp to almost any system, even one with a factory radio.

High-tech Class-D innards

Beefy internal components and the cleverly designed Thermal Flow chassis help the amp produce its power efficiently, with little stress to your vehicle's electrical system. Alpine designed this amp to exert tight control over speaker cones and deliver a very wide frequency response, so you'll experience a very realistic soundstage. A special comparator circuit corrects the output using the original input signal, minimizing phase issues for precise, high-fidelity sound.

Hidden controls and plug-in connectors

The amp's tuning controls sit protected under a removable top panel. Nifty speaker and power wire plugs make it easy to install or remove the amp, while ensuring tight connections and guaranteeing that your speakers work in unison. Gold-plated RCA inputs, outputs, and power connections resist corrosion and signal degradation. For a creative touch, you can paint the amp's trim panels to match or contrast with your vehicle's interior decor.

Product Highlights

• 4-channel car amplifier
• 120 watts RMS x 4 at 4 ohms (175 watts RMS x 4 at 2 ohms)
• 350 watts RMS x 2 at 4 ohms in bridged mode (4-ohm stable in bridged mode)
• CEA-2006 compliant
• Class-D amplifier technology
• frequency response: (+0/-1 dB) 15 to 30,000 Hz
• variable high- and low-pass filters (50-400 Hz, 12 dB/octave)
• preamp and speaker-level inputs
• speaker-level inputs require speaker wire to RCA adapters
• quick-connect speaker connectors fit wire up to 8-gauge
• optional RUX-KNOB.2 wired remote level control for bridged channels 3/4
• fuse rating: 35A x 2
• wiring and hardware not included with amplifier
• 4-gauge power and ground wire recommended
• 11-3/4"W x 2"H x 7-5/8"D
